AT340IP

  SDI to IP Encoder

  HEVC/H.265

  H.264/AVC

  Supports NDI



spade spade

  Downloads:

spade spade

  Specification:

    Video
  Input: HD-SDI
  Input Resolution Max: Max 1080P or 1080i resolution, Max 60fps frame rate
  Encoding Type: HEVC /H.265 and H.264 /AVC and MJPEG for selection
  Encoding Levels: H.265 main profile; H.264 high /main /baseline profile
  Video Bitrate: Adjustable from 32kbit /s to 32mbit /s
  Bitrate Control: CBR or VBR or Strong CBR for selection
  Output Resolution: It is adjustable, max 1920x1080P /60fps
  Video Pre-processing: De-interlacing, noise reducing and sharpening
    Audio
  Input SDI embedded audio or external stereo audio(3.5mm)
  Audio Encoding: AAC, AAC+, AAC++, MP3, MP2, AC3, G.711
  Sampling Rate: 44.1KHz, 48KHz
  Bitrate Control: Adjustable from 48000~320000
  Sampling Accuracy: 24bit
  ONVIF: G.711
    Network
  Interface: 1000M Ethernet port (RJ45)
  Streaming Protocol: NDI, HTTP, UDP, RTSP, RTMP, SRT, HLS(M3U8), Multicast, ONVIF, RTP, Unitcast, RTMPS, etc.
  Control Panel: Webpage control panel or APP
  Firmware Upgrade: Firmware is upgradeable
    General
  Dimension 130 x 105 x 30 mm (W x L x H )
  Net Weight: 0.3kg
  Temperature: 0 to 45 (For working), -20 to 80 (For storing)
  Input: Voltage DC 12V /1A
  Power Consumption: 5w

  Standard Features:

  Embedded Hi Linux system, stable and effective
  Support wide area network remote management (via port forwarding)
  Support HEVC /H.265 and MPEG-4 /H.264 AVC and MJPEG video encoding for selection
  Support AAC, AAC+, AAC++, MP3, MP2, AC3, G.711 audio encoding for selection
  Support NDI, SRT, HTTP, UDP, RTP, RTSP, RTMP, RTMPS, HLS (M3U8), FLV, ONVIF
  Supports Unicast and Multicast Streaming Protocol
  Selection of SDI embedded audio or external audio as output audio
  Upgradable Firmware
  Configuration of the encoder settings via webpage
  SDK, API and CGI for secondary development
  Network interface full-duplex mode with 1000M speed
  Support HDCP and HD blue-ray
  Easy restoration of the default configuration
  Stable and effective, support 7 x 24h working time
  Available in multichannel 1U or 3U rack structure, up to 16 encoder cards in 1 unit
